Compression Column Load Cell

LL418-M1

Vehicle Load Cells

Dimensions:

Unit: mm

Cap./Size	H	D1	D2	D3
7.5~22.5t	150	68	46	148
30~40t	200	85	64	165
50t	238	85	64	165

Product Characteristics:
Vehicle load cells LL418-M1 is a stainless steel self centering rocker column load cell with complete hermetic sealing. We can produce the load cell with analog load cell, digital load cell, wireless load cell, high temperature load cell, anti-lighting load cell. It is application for weighbridges, hoppers scale, tanks and silos scale, truck scales, weighing Scale, weighing equipment, weighing, standard truck scales, portable truck scales, on-board truck scales, truck weigh scale, truck weigh scales, electronic truck scale, digital truck scale, axle scale, digital railway scale, explosion-proof truck scale, fully automatic truck scale, car scale, construction truck weighing scale, weighbridge, weighing systems.
Technical Parameter:

Rated Load:	7.5/15/22.5/30/40/50t
Sensitivity:	(2.0±0.1%) m V/V
Combined Error:	±0.02% F.S
Creep Error﹙30min﹚:	±0.02% F.S
Zero Balance:	±1% F.S
Temp. Effect On Zero:	±0.02% F.S/10℃
Temp. Effect On Span:	±0.02% F.S/10℃
Input Resistance:	750±5Ω
Output Resistance:	702±2Ω
Insulation Resistance:	≥5000MΩ
Operating Temperature Range	-30~+70℃
Maximum Safe Over Load:	150%F.S
Ultimate Over Load:	300%F.S
Recommend Excitation Voltage:	10~12V DC
Maximum Excitation Voltage:	15V DC
Sealing Class:	IP68
Element Material:	-A: Alloy Steel, -SS: Stainless Steel
Cable:	Length=13m(7.5~40t), 16m(50t),
Citation:	GB/T7551-2008/ OIML R60
Mode Of Connection:	Red(Input+),Black(Input-),Green(Output+),White(Output-)
