Mobile lifting Table

Product Name:Mobile lifting platform
Product Presentation:Overview: Mobile lifting platform can walk fast and slow under different height working condition..It can operate the platform easily in the air,continuously complete up and down,forward,backward,turning work,etc. Our product use high quality structural steel.laster welding electronic manipulator,single-side welding,double molding process.Italian imported hydraulic pump station or Anshan joint hydraulic pump station.Space cartridge valve technology.Platform equipped with level alarming device, balance valve, automatic safety board alarm device.Platform is safe ,reliable and durable.Its work height can reach 12 meters,can load 300 kilograms.Fence can be horizontal extension greatly to expand the scope of work.Warranty of the machine is one year,and the key part is five years.It suitable for customers who needs aloft work in the factory and workshop, square lobby airport, park etc.

Classification:
1.Mobile aluminum alloy lift platform: New design of a new generation of products,using a new type of aluminum alloy sections.High-strength section can make deflection and swing of the platform minimum. It looks light,but it can play the the maximum lifting capacity in the tiny space.It can make single aloft work easily,also can move to work.
2. Stationary aluminum alloy lift platform: New design of a new generation of products, using a new type of aluminum alloy section.High-strength section can make deflection and swing of the platform minimum. It looks light,but it can play the the maximum lifting capacity in the tiny space.It can make single aloft work easily.Only can be fixed to work. .

3. Telescopic mesa aluminum alloy lift platform: Expansion mesa lift platform is custom made with four-wheel mobile or vehicular . This operation platform can stretch out and draw back free when it works aloft ,so that can increase scope of work! It can be customized according to the customer’s requirements.

4. Folding lift lifting platform: Household folding elevator, belongs to a kind of elevator, especially a household folding lift.Its beams are composed with two pieces of steel structure, and they are welded and linked by several inverted "U" glyph connection card.The middle parts form a gap.The front and rear ends can be put into the track which is forms by gap,
.It overcomes the defect of domestic lifter which is unreasonable structure and inconvenient using.The utility model has lots of advantages,such as reasonable structure, easy manufacturing, low cost, easy using, practicability ,etc.It can be used by more than one family ,and also be used by a single family.

5. Wall elevator: It suitable for the workplace which is can’t excavation pit,with single and double down to type. This lift’s operation is stable,safe and reliable.It is applicable to the supermarket, hospital, restaurant, shop goods transmission, etc.

6. Vehicular elevator: Aloft working equipment which is installed in the car. It composed with Special chassis, working jib, three-dimensional rotation mechanism, flexible clamping device,hydraulic system, electrical system and safety device,etc.

7. Scissor lift: Aloft working special equipment which is widely used . Its shear fork mechanical structure makes knee lifting a higher stability,.The spacious operation platform and high bearing capacity can make operating range larger, and it suitable for more people to operate at the same time . It makes high-altitude operations more efficient, safe and more protection.

8. Chain elevator:chain ascension by adopting the cylinder driving,,so it’s named for chain elevator.

9. Crank lift : Lifting equipment for high-altitude operations, it can overcome obstacles to do aerial work..Platform can walk and work at the same time no matter lift to any location.Compact structure, flexible steering.The width of the site can ensure the equipment enter the narrow channel and crowded work area.The standby power plant, can make the operate platform reset.Its convenient mode of transport can be towed anywhere. Easy to identify the operator panel, multiple mechanical, electrical and hydraulic safety protection, advanced integrated hydraulic electrical integration system. Crank aerial vehicles are widely applicable to the installation,maintenance and climbing operation of the municipal, electricity, street lighting, advertising, communications, photography, landscape, transportation, docks, airports, ports, large industrial and mining industries.

Features:
The Scissor mobile is widely used special equipment for aerial work operations. Scissor mechanical structure makes its lift table high stability.Its wide operating platform and high carrying capacity, greater range of aerial work and suitable for more people to work at the same time. It makes high-altitude operations more efficient, safe and more protection.

Functions:
Crank mobile can overhang the operation, across certain obstacles or movement in a multi-point operations.This platform’s carrying capacity is large enough for two or more people operate at the same time,and can be equipped with certain equipment.The lift platform has good mobility, convenient transfer venue.It looks nice and suitable for indoor and outdoor operation and storage. For stations, docks, shopping malls, stadiums, residential property, factories, mines and workshops, and other large-scale operations.
Mobile aerial work platforms rely on battery-driven walking, walking and turning can control countertops aerial work platforms. It’s the most advanced aerial equipment at present.It can walk  at the maximum height.Potholes protection system provides maximum security.It operate highly automatic,.Safe ground clearances can make indoor operations to be carried out.It is strong and reliable,easy to maintain, standard accessories, no traces of tires, the slopes alarm, two-wheeled.

How to choose and buy mobile lifting platform:
With the development of social science and technology, more and more extensive use of aluminum lift, hydraulic lifting machinery construction, civil engineering, and people's daily life are inseparable, and many businesses to grasp this opportunity and have invested in the plant, lifting machinery like bamboo shoots after the company along with rain the provisional legislature in the major industrial city, but the the lift machinery industry is still unusually hot in short supply, it can be seen from the side, the rapid social development, driven by the development of the industry as a whole as well as the needs of the people, however asthe buyer how to choose a good company merchandise in the forest of lifting machinery has become an important topic.

Optional lifting machinery, not blindly buy, to do adequate market research, as well as field trips, to determine the company's size and the degree of its credibility. This is first and foremost is a must now market many small-scale enterprises in order to reap the violence and cut corners, thereby elevating product quality greatly reduced, although they will be sold very cheap, but this mechanical time not long, and the risk factor large. Therefore, as the purchaser is not just for the sake of a little price a little cheaper and lead to greater regret.

Comprehensive survey, choose a better cost-effective lifting machinery, from its technical parameters as well as practicality and versatility to choose, usually aluminum lift machinery, including (car lift, fixedlifts, hydraulic lifting platform, scissor lift, etc.) for each of the technical parameters and purposes have a little different, but there are many features similar places, therefore, as a customer you want to with the purpose of the purchase, that youbuy lift mechanical what to do, and what kind of lifting machinery to meet your needs and uses.

The last point is that, after the arrival of the equipment, the the unpacking acceptance to check the random technical data are complete, random parts, tools, accessories list, equipment and accessories for damage, defects, and well out of the box and acceptance records.

Hydraulic oil pressure formed by the vane pump, oil filter, explosion-proof solenoid valve, throttle valve, hydraulic control one-way valve, balance valve into the lower end of the hydraulic cylinder, hydraulic cylinder piston upward movement, enhance weight material, the upper end of the hydraulic cylinder return oil back into the tank by the explosion-proof solenoid valve rated pressure relief valve to adjust observed through the pressure gauge pressure gauge readings.
The downward movement of the piston of the hydraulic cylinder (both weights are decreased). Hydraulic oil into the upper end of the hydraulic cylinder explosion-proof solenoid valve, oil return through the lower end of the hydraulic cylinder balancing valves, pilot-operated check valve, throttle valve, explosion-proof solenoid valve back to the tank. The weight down smooth, safe and reliable braking, set the way back to the oil balance valve, balance loop, keep up the pressure, the rate of decline is not heavy, adjust the flow by the throttle valve to control the lifting speed. Safe and reliable for the brake, to prevent accidents, increase pilot operated check valve that hydraulic lock to ensure safety self-locking hydraulic pipeline accidents burst. Install of overloading voice alarm used to distinguish to overloading or equipment failure.

Mobile lifting platform maintenance:

The hydraulic oil is exhausted discarded tighten the fitting pulled out the oil filter, cleared, with compressed air clean, and then back into the fuel tank and connected piping. (Put on new oil, do not inherit the old oil or moving parts in the hydraulic lift system will accelerate wear.)
Remove and disassemble the lift down valve plunger blowing with compressed air, and then mount the re-placement.
Check all hydraulic pipes and joints. The pipe can not be damaged, the joint can not loose, it is necessary to tighten all joints.
Lift the end of the year maintenance
Hydraulic oil oily and oil level. The LIFTS throughout rises, and when in this position, hydraulic ground should be above the bottom 40 to 50 mm. Found hydraulic oil to darken, tacky or gravel and other foreign matter, should be replaced (32 # hydraulic oil).
4. Various parts are filling some lubricants to extend the lift bearing life. Check the hydraulic lift wheel, intermediate shaft and bearings, cylinder pin and bearing, boom hinge shaft and bearings for wear.
Between 5 any part of the hydraulic system, it is necessary first of all relief, in order to avoid pressure oil spray, lift workbench Passed decline.
6. Relief valve shall be arbitrarily adjusted. Each component in the demarcation of pressure in the hydraulic lift system works. Arbitrary adjustment relief valve may be caused by the normal operation of the hydraulic system.
The inspection of the lift work platform below required Diaozhu, supporting the lift work platform, prevent lift Passed decline.
8 non-professional staff shall not be easily removable appliances, in order to prevent electric shock or misconnection.
